Tycon Power TP-DCDC-1248G, 9-36VDC IN. 48V 20W Gigabit Passive PoE OUT. DC to DC Converter and PoE Injector

Description

Tycon Power TP-DCDC-1248G 1Gbps 9-36VDC IN 48V OUT 24W DC to DC PoE Description: The TP-DCDC-1248G offered by Tycon Power is a low cost and high efficiency solution for those requiring Passive Power over Ethernet from a 12VDC or 24VDC voltage source like a battery system or vehicle. They have an integrated POE injector to apply the power and data output to the CAT5/6 Ethernet cable. The output voltage is regulated and protected. They have two common (-) and two (+) for connecting 2 power sources, such as a primary with a backup power source. They have various protections for surge, short circuit and overload. The input and output are isolated. A metal enclosure model is available for industrial applications. They accept gigabit data-in to a shielded RJ45 Jack and provide gigabit data-out and PoE power on the shielded RJ45 output jack. They work by supplying power on Ethernet pins 4,5(V+) and 7,8(V-). They have various protections for surge, short circuit and overload. The other models have power outputs up to 24W. SKU:TP-DCDC-1248G SPEC SHEET:Click Here USER GUIDE:Click Here DIMENSIONAL DRAWING:Click Here Features • Input Voltage 12VDC or 24VDC (Range 9-36VDC) • Passive PoE Output, 48VDC • Dual Inputs for Connecting 2 Power Sources • Integrated 10/100/1000MB PoE Inserter • High Power up to 24W • Low Self Consumption Power • Short Circuit, Over Current and Reverse/Over Voltage Protect • High Temperature Operation • Compact Size – Maximize Available Space • I.T.E. Power Supply, UL Listed Applications • 12V / 24V Battery Systems, Vehicle Applications • Wireless Access Points and Client Devices • IP Phone and Security Camera Systems

Customer reviews

Delivery policy

Shipping Information

We believe in clear and straightforward service, and that starts with how your order is delivered. Before completing your purchase, we encourage you to review our shipping information so you know exactly what to expect.

Our Shipping Policy outlines order processing times, delivery methods, and what happens once your order has been dispatched.

This policy forms part of your purchase agreement and is intended to provide transparency and confidence when placing your order.

Returns & Exchanges Policy

Returns & Exchanges Policy

We understand that sometimes a return or exchange may be necessary. To ensure the process is handled fairly and efficiently, we ask that all customers review our policy before submitting a request.

Our Returns & Exchanges Policy explains eligibility requirements, timeframes, and the steps involved in requesting a return or exchange.

Please note that this policy applies to all purchases and forms part of the terms and conditions of sale.

Tycon Power TP-DCDC-1248G, 9-36VDC IN. 48V 20W Gigabit Passive PoE OUT. DC to DC Converter and PoE Injector

Available:

Sold out

SKU: NHU-TP-DCDC-1248G

Category: DC Power Cables, Electronics, Electronics > Electronics Accessories > Cables, Network - SMB, Tycon, Tycon - POE Injector/Splitter/Switch

Tags: 1248G, DCDC, Network - SMB, NHU-TP-DCDC-1248G, Power, TP, Tycon, Tycon - POE Injector/Splitter/Switch

Tycon Power TP-DCDC-1248G 1Gbps 9-36VDC IN 48V OUT 24W DC to DC PoE Description: The TP-DCDC-1248G offered by Tycon Power is a low cost and high efficiency solution for those...

Regular price $154.00 Sale ~~$141.65~~
